RadioRanked verdict
WLN
WLN KD-C1
The KD-C1 is a highly portable, budget UHF HT for basic simplex and local repeater work. Its performance is solid given its price point, though programming requires some effort.
Decision helper
Is this radio right for you?
Yes, if you're…
- ✓Budget-conscious new technicians
- ✓Backup radio for events or camping
- ✓Simplex communication needs
- ✓Operators needing portability
Skip it, if you're…
- ✕Advanced field deployment radios
- ✕Operators needing high-end features
- ✕Users expecting out-of-box functionality
Tradeoffs
The good and the bad
What we like
- Very compact and lightweight design
- Excellent value for the price point
- Easy programming via CHIRP software
- Adequate range for local repeaters
What we don't
- Factory programmed with licensed frequencies
- No visible display or channel lock feature
- Requires external programming cable
- Potential audio reception issues reported
Proprietary RR score
How we scored it
Scores combine specs, Amazon buyer sentiment, and our testing framework. How we score →
Ready to buy?
Fast Prime shipping, no-questions-asked returns through Amazon.
5.00W
TX Power
1500mAh
Battery
16
Channels
198g
Weight
Extracted from the top buyer reviews we analysed
Themes from top buyer reviews
Portability and Size
Users praise its small, light, and compact build.
Programming Ease
CHIRP software makes frequency setup simple.
Out-of-Box Setup
Factory frequencies often require manual correction.
Performance vs Cost
Exceeds expectations for its low price tag.
Overview
This radio is aimed squarely at new Technicians needing a first HT on a tight budget, or experienced operators wanting a disposable backup for events, volunteer work, or situations where losing a radio is a real possibility. It is not a feature-rich rig, and it does not pretend to be. At this price point, the honest comparison is other budget UHF handhelds, not your Yaesu or Kenwood.
The KD-C1 covers UHF 400 to 470 MHz with up to 5W output, 16 memory channels, and a 1500mAh Li-ion pack rated for roughly eight hours on a 5-5-90 duty cycle. Portability scores well for its class given the compact 110x50x32mm footprint and 198g weight with battery. Receiver sensitivity is rated at 0.20 uV at 12dB SINAD, which is adequate for simplex and local repeater work. The 25kHz channel spacing covers most North American UHF repeater assignments without issue.
There is no verified IP rating, so treat the waterproofing claim with appropriate skepticism in the field. For a licensed operator needing a second HT for a net, an event, or a loaner radio for a new ham, the value case is reasonable. If you need APRS, DMR, cross-band capability, or a full memory bank, look elsewhere.
Specifications
| Price | $14.99 |
| TX Power (High) | 5.00W |
| Memory Channels | 16 |
| Weight | 198g |
| Battery | 1500 mAh |
| FCC Authorization | Covers FRS only (Part 95B) |
| FCC ID | 2AQX5KD-C1 |
| FCC Rule Parts | Part 95B |
| FCC Grant Date | 2020-11-30 |
| size | 96*55*22mm |
| color | Black |
| UPC | 764210571612 |
| Color | Black |
| Voltage | 3.7 Volts |
| Impedance | 50 Ohms |
| Tuner Type | UHF |
| Model Number | 4350441575 |
| Audible Noise | 45 Decibels |
| Built-In Media | Two Way Radio, Battery, Belt Clip, Instructions |
| Frequency Range | 400 470 mhz |
| Mfr Part Number | 4350441575 |
| Compatible Devices | FRS Two-Way Radios, FRS Compatible Headsets, FRS Compatible Earpieces |
| Additional Features | Uhf |
| Battery Average Life | 8 Hours |
| Water Resistance Level | Waterproof |
| Item Dimensions D x W x H | 1.97"D x 1.26"H |
Key Features
- UHF coverage spans 400 to 470 MHz; no VHF band included
- Maximum TX output rated at 5W; intermediate and low power levels unlabeled in spec sheet
- 16 memory channels only; adequate for simplex and a handful of local repeaters
- 25kHz channel spacing standard; narrow 12.5kHz operation not confirmed in published specs
- Receiver sensitivity rated at 0.20 uV (12dB SINAD); acceptable for local simplex and repeater use
- 1500mAh Li-ion battery; manufacturer rates approximately 8 hours on light duty cycle
- Compact form factor at 110x50x32mm and 198g with battery; no stated IP rating despite waterproof claims
